Superior NVMe Read/Write performance with speeds up to 3,500/3,300 MB/s *V-NAND reliability backed by up to 5 yr. warranty
Type
Product Type
SSD
Series
970 EVO Plus
Usage Application
Client PCs
Interface
PCIe Gen 3.0 x 4, NVMe 1.3
Application
Consumer
Yes
Storage
Capacity
250GB (1GB is equal to 1 Billion byte by IDEMA)
Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Key Features
Sequential Read Speed
Up to 3,500 MB/s ( Performance may vary based on system hardware and configuration)
Sequential Write Speed
Up to 2,300 MB/s ( Performance may vary based on system hardware and configuration)
Random Read Speed
Random Read (4KB, QD32): Up to 250,000 IOPS, Random Read (4KB, QD1): Up to 17,000 IOPS ( Performance may vary based on system hardware and configuration)
Random Write Speed
Random Write (4KB, QD32): Up to 550,000 IOPS, Random Write (4KB, QD1): Up to 60,000 IOPS ( Performance may vary based on system hardware and configuration)
Controller
Samsung Phoenix Controller
NAND Flash
Samsung V-NAND 3-bit MLC
Cache Memory
Samsung 512MB Low Power DDR4 SDRAM
Trim Support
Supported
AES Encryption
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
S.M.A.R.T. Support
Supported
GC (Garbage Collection)
Auto Garbage Collection Algorithm
WWN Support
Not Supported
Device Sleep Mode Support
Yes
Temperature proof
Yes
NVMe
Yes
Gaming SSDs
Yes
General
Average Power Consumption (system level)
Average: 5 W Maximum: 8 W (Burst mode) ( Actual power consumption may vary depending on system hardware and configuration)
Power consumption (Idle)
Max. 30 mW ( Actual power consumption may vary depending on system hardware and configuration)
Voltage
3.3 V +/- 5 % Allowable voltage
Reliability (MTBF)
1.5 Million Hours Reliability (MTBF)
Environmental Specs
Operating Temperature
0 - 70oC Operating Temperature
Shock
1,500 G and 0.5 ms (Half sine)
Form Factor
Product
M.2 (2280)
Software
Management SW
Magician Software for SSD management
Item Dimension (L"xW"xH")
6 x 4 x 1
Weight
1.00 LB
Warranty Information
5 years or 150TB TBW
